702
APPLICATIONS: Commercial | Retail | Residential
- The Razor series offers high-efficiency illumination with a sleek, modern design.
- With superior lighting performance and versatile mounting options, it adapts to various applications.
- Dimming controls provide flexibility and enhanced user experience.
- A long lifespan ensures reliable and customizable lighting solutions.
IP
20
Flicker
Free
DALI
2
Luminaire Specification
Model702
CCT2700 / 3000 / 3500 / 4000 / 5000
Beam Angle110°
CRI80 / 90
Lifetime50,000 hrs
ControlPhase Cut / 0-10V / DALI / Casambi
IP Rating20
Dimension85(W) x 85(H)
FinishWhite / Black
InstallationRecessed
Warranty5 years
Details
Datasheet| Product Code | Wattage (W) | Lumen Output (lm) | 光效 (lm/m) | CCT (K) | CRI | Downloads |
|---|---|---|---|---|---|---|
| 702-827 | 24.4 | 2386 | 97.8 | 2700 | 80 | IES |
| 702-830 | 24.4 | 2498 | 102.4 | 3000 | 80 | IES |
| 702-835 | 24.4 | 2570 | 105.3 | *3500 | 80 | IES |
| 702-840 | 24.4 | 2642 | 108.3 | 4000 | 80 | IES |
| 702-850 | 24.4 | 2642 | 108.3 | *5000 | 80 | IES |
| 702-927 | 27.2 | 2466 | 90.6 | 2700 | 90 | IES |
| 702-930 | 27.2 | 2546 | 93.6 | 3000 | 90 | IES |
| 702-935 | 27.2 | 2610 | 95.9 | *3500 | 90 | IES |
| 702-940 | 27.2 | 2642 | 97.1 | 4000 | 90 | IES |
| 702-950 | 27.2 | 2642 | 97.1 | *5000 | 90 | IES |
* Special Order
Customization Support
We support multi-dimensional customization including power, color temperature, length, and dimming protocols. Welcome to inquire.
